How To Build A Simple Dashboard Using React And Tailwind CSS

In this tutorial, I will guide you to build a simple simple sidebar menu using React js, and Tailwind css, and React Router.

Installing React And Tailwind CSS

Installing React

We will start by installing react with vite. Let’s run the command below in our terminal

npm create vite@latest

Make sure you follow the subsequent instructions in the terminal to completely install React.

Installing Tailwind CSS

Run the command below in your terminal to install tailwind css

npm install tailwindcss @tailwindcss/vite

When you’re done , open your index.css file and add the following line of code at the top

/*index.css */

@import "tailwindcss";

Make sure your vite.config.ts, looks like the one below

//vite.config.ts

import { defineConfig } from "vite";
import tailwindcss from "@tailwindcss/vite";
export default defineConfig({
  plugins: [tailwindcss()],
});

Installing React Router

Run the command below in your terminal

npm install react-router@latest

Installing Lucide React

Run the command below in your terminal

npm install lucide-react

Creating Components and Pages For Our SideBar Menu

Let’s go to the src folder and create two folders and name one pages, and the other one components.

The Pages Folder

In this folder, we will create files called Dashboard.tsx, Users.tsx, Settings.tsx,Posts.tsx and these will be our pages . The code in our pages files will look like the ones below;

//Dashboard.tsx

export const Dashboard = () => {
  return <div> Dashboard</div>;
};

//Users.tsx

export const Users = () => {
  return <div className="flex items-center justify-center">All Users </div>;
};

//Settings.tsx

export const Settings = () => {
  return <div className="flex items-center justify-center">Settings Page </div>;
};

//Posts.tsx

export const Posts = () => {
  return <div className="flex items-center justify-center">Posts </div>;
};

Note: You might see different contents in your pages.

Configure React Router for the project

Remove all the code in your App.tsx and paste this code

// App.tsx

import {Users} from "./pages/Users";
import {Posts} from "./pages/Posts";
import {Settings} from "./pages/Settings";
import {Layout} from "./components/Layout";
import {Dashboard} from "./pages/Dashboard";


export default function App(){

return(

<Routes>

<Route element={<Layout />}>
  <Route path="dashboard" element={<Dashboard />} />
  <Route path="posts" element={<Posts />} />
  <Route path="users" element={<Profile />} />

  <Route path="settings" element={<Settings />} />
</Route>


    </Routes>

</Routes>
)
}

Let’s now create a shared Layout for the pages. We can do this by creating a new file in the components folder, and name it Layout.tsx.

import React from "react";
import { Outlet } from "react-router";
import {SideBar} from "./SideBar.tsx

const Layout = () => {
  <div className="flex flex-row">
    <Sidebar />
    <Outlet />
  </div>;
};

Setting Up The main.tsx

Now, let’s go to the main.tsx menu and make sure we have this code there

import { StrictMode } from "react";
import { createRoot } from "react-dom/client";
import {BrowserRouter}  from 'react-router'
import "./index.css";

import App from "./App";

createRoot(document.getElementById("root")!).render(

{" "}

<StrictMode>
  <App />
</StrictMode>
);

Final Code

Create a file called SideBar.tsx this will be our Sidebar menu component. Copy and paste the code below into your SideBar.tsx and remove the old code.

//Sidebar.tsx

import {
  FileText,
  LayoutDashboard,
  Settings,
  Users,
  Menu,
  X,
} from "lucide-react";
import { useState } from "react";
import { Link, useLocation } from "react-router"; // ensure you're using react-router-dom

interface NavItem {
  title: string;
  href: string;
  icon: React.ReactNode;
}

const navItems: NavItem[] = [
  {
    title: "Dashboard",
    href: "/dashboard",
    icon: <LayoutDashboard className="h-5 w-5" />,
  },
  {
    title: "Users",
    href: "/users",
    icon: <Users className="h-5 w-5" />,
  },
  {
    title: "Posts",
    href: "/posts",
    icon: <FileText className="h-5 w-5" />,
  },
  {
    title: "Settings",
    href: "/settings",
    icon: <Settings className="h-5 w-5" />,
  },
];

export const SideBar = () => {
  const location = useLocation();
  const [open, setOpen] = useState(true);

  const pathname = location.pathname;

  return (
    <div className="flex">
      {/* Toggle Button */}
      <button
        type="button"
        className="absolute top-4 left-4 z-50 bg-gray-200 p-2 rounded-md md:hidden"
        onClick={() => setOpen(!open)}
      >
        {open ? <X className="h-6 w-6" /> : <Menu className="h-6 w-6" />}
      </button>

      {/* Sidebar */}
      <aside
        className={
          `flex items-center gap-3 rounded-md px-3 py-2 text-sm font-medium hover:bg-gray-100 ` +
          `${
            pathname === item.href || pathname.startsWith(`${item.href}/`)
              ? "bg-gray-200"
              : ""
          }`
        }
      >
        <div className="p-5">
          <h2 className="text-lg font-bold mb-6">My App</h2>
          <ul className="space-y-2">
            {navItems.map((item) => (
              <li key={item.href}>
                <Link
                  to={item.href}
                  onClick={() => setOpen(false)}
                  className={cn(
                    "flex items-center gap-3 rounded-md px-3 py-2 text-sm font-medium hover:bg-gray-100",
                    pathname === item.href ||
                      pathname?.startsWith(`${item.href}/`)
                      ? "bg-gray-200"
                      : ""
                  )}
                >
                  {item.icon}
                  <span>{item.title}</span>
                </Link>
              </li>
            ))}
          </ul>
        </div>
      </aside>

      {/* Main content */}
      <main className="flex-1 ml-0 md:ml-64 p-6 transition-all duration-300">
        <h1 className="text-2xl font-bold">Main Content Here</h1>
      </main>
    </div>
  );
};

Conclusion

Now we have a very beautiful sidebar menu

Your final dashboard will look like this
